Leica HDS 4050 ScanStation 2 Surveying Laser Scanner
$2,200.00$9,150.00 (-76%)
Leica HDS 4050 ScanStation 2 Surveying Laser Scanner
With a 10-times boost in maximum instantaneous scan speed and the full freedom and accuracy of a total station, Leica ScanStation 2 has lifted laser scanning to the next level.This speed and productivity boost builds on the already industry-leading versatility of the ScanStation™ class of laser scanner to make High-Definition Surveying™ (HDS™) profitable for even more as-built and topographic survey projects.
Leica HDS 4050 ScanStation 2 Surveying Laser Scanner
Leica ScanStation 2A New Level of Versatility and Speed in Laser Scanners
With a 10-times boost in maximum instantaneous scan speed and the full freedom and accuracy of a total station, Leica ScanStation 2 has lifted laser scanning to the next level.This speed and productivity boost builds on the already industry-leading versatility of the ScanStation™ class of laser scanner to make High-Definition Surveying™ (HDS™) profitable for even more as-built and topographic survey projects.
Leica HDS 4050 ScanStation 2 Surveying Laser Scanner
With a 10-times boost in maximum instantaneous scan speed and the full freedom and accuracy of a total station, Leica ScanStation 2 has lifted laser scanning to the next level.This speed and productivity boost builds on the already industry-leading versatility of the ScanStation™ class of laser scanner to make High-Definition Surveying™ (HDS™) profitable for even more as-built and topographic survey projects.
Leica ScanStation Specifications :
| Leica ScanStation 2 Performance Specifications | |
| Instrument Type | Pulsed, dual-axis compensated, very-high speed laser scanner, with survey-grade accuracy, range, and field-of-view |
| User interface | Notebook or Tablet PC |
| Camera | Integrated high-resolution digital camera |
| Accuracy of single measurement | Position* 6 mm Distance* 4 mm Angle (horizontal/vertical) 60μrad/60μrad (3.8 mgon/3.8 mgon) ** |
| Laser spot size | From 0 – 50 m: 4 mm (FWHH-based); 6 mm (Gaussian-based) |
| Modeled surface precision/noise | 2mm ** |
| Target acquisition | 2 mm std. deviation |
| Dual-axis compensator | Resolution 1 “, dynamic range +/- 5′ |
| Data integrity monitoring | Periodic self-check during operation and start-up |
| Laser scanning system | |
| Range | 300 m @ 90 %; 134 m @18 % albedo |
| Scan Rate | Maximum instantaneous: up to 50,000 points/sec Average: dependent on specific scan density and field-of-view |
| Scan Density | <1 mm max, through full range; fully selectable horizontal and vertical spacing; single point dwell capability |
| Laser Class | 3R (IEC-60825-1), visible green |
| Lighting | Fully operational between bright sunlight and complete darkness |
| Power Supply | 36 V; AC or DC; hot swappable |
| Specifications subject to change without notice See Leica ScanStation 2 Product Specifications for full technical data* At 50 m range, one sigma ** One sigma |
