Olympus EPOCH-650 Ultrasonic Flaw Detector

Olympus EPOCH 650 Ultrasonic Flaw Detector

Olympus Epoch 650 Ultrasonic Flaw Detector has been developed for use in almost any inspection surrounding, from bench top testing performed in a laboratory to extreme outdoor and dangerous conditions.

The EPOCH 650 has been developed for IP rating in either knob (IP66) or navigation pad (IP67) configurations and tested to very high reliability and environmental standards. Hence, it enables users in any inspection surrounding to feel confident in both the durability and performance of the instrument.

Key Features

Developed to fulfill the needs of ISO 22232-1
PerfectSquare tunable square wave pulser
Full-screen A-scan mode provided
Digital high dynamic range receiver
15+ hours of battery life
Standard dynamic DAC or TCG and onboard DGS/AVG
Big and complete VGA sunlight readable display
Multiple on-board report formats
Comes with thirty digital filters for enhanced signal-to-noise ratio
Optional analog output
Provided with alarm and VGA outputs
2 kHz PRF available for quick scanning
MicroSD memory card available for data transfers
Knob or navigation pad configurations can be adjusted
Optional Corrosion Module software with Encoded B-scan
USB On-The-Go (OTG) for PC communication

Designed for All Inspection Environments

Olympus Epoch 650 Ultrasonic Flaw Detector Designed for use in nearly any inspection environment, from bench top testing in a laboratory to extreme outdoor and hazardous conditions. Designed for IP rating in either knob (IP66) or navigation pad (IP67) configurations, and tested to very high environmental and reliability standards, the EPOCH 650 allows users in any inspection environment to feel confident in both the performance and durability of the instrument.
